VIVOTEK CC9391-HV 8MP Panoramic IP Camera 180° 20m IR WDR Pro
Every angle. One 180° view.
A compact 8MP panoramic IP camera with a 180° horizontal view, 20m IR and WDR Pro. It covers wide areas with one camera and reads clearly in bright, dark or mixed light.

Wide spaces leave blind spots.
A narrow-view camera sees only part of an area, so coverage gaps appear. A single 180° panoramic view reduces the number of cameras needed to watch a wide space.
Built for wide, tough spaces
Panoramic coverage, strong low-light performance and a hardened housing in one compact camera.
180° panoramic coverage
The 180° horizontal view with an 8MP CMOS sensor captures a wide scene at 30 fps at 3840x2160 (WDR On).

Horizontal panoramic view
One fixed 2.53mm lens covers a wide scene in a single camera.
WDR Pro for mixed light
WDR Pro (120 dB) provides extreme visibility in scenes with high light contrast.
Low-light visibility
SNV (Supreme Night Visibility) and 3D noise reduction support low-light conditions, with infrared night vision to 20.00m.
Weather and impact resistant
The IP66-rated, IK10-rated housing is weather-proof and vandal-proof, and the anti-ligature design suits demanding sites.
Everything you need to know.
| Brand | VIVOTEK |
| Model | CC9391-HV |
| Camera Type | Panoramic Camera |
| Maximum Video Resolution | 3840 x 2160 |
| Focal Length | 2.53mm |
| Lens Type | Fixed |
| Night Vision Distance | 20.00m |
| Impact Protection Rating | IK10 |
| Indoor/Outdoor | Outdoor |
| Built-in Microphone | Yes |
| TAA Compliant | Yes |
| NDAA Compliant | Yes |
VIVOTEK CC9391-HV 8MP Panoramic IP Camera 180° 20m IR WDR Pro
8MP sensor captures fine detail across the entire panoramic frame, supporting clear identification and forensic-quality playback. 20-meter infrared range enables round-the-clock monitoring in low-light and zero-light conditions. Wide Dynamic Range Pro technology balances exposure in mixed lighting—critical for entrances, windows, and mixed-brightness zones.
IP67-rated enclosure withstands dust, moisture, and harsh outdoor conditions. PoE-powered for simplified installation and reliability. H.264/H.265 codec support optimizes bandwidth and storage without sacrificing image quality. Ideal for perimeter security, parking areas, warehouse floors, and any space where panoramic awareness matters.
Need help with compatibility?
Looking for a manufacturer part number, compatible replacement, or quantity order? Contact Raztechs for sourcing and quote support.

VIVOTEK CC9391-HV, ready to order.
- Camera Type: Panoramic Camera
- Maximum Video Resolution: 3840 x 2160
- Focal Length: 2.53mm
- Lens Type: Fixed
